Elastomeric U-Cups and Wipers

ELASTOMERIC U-CUPS AND WIPERS

Type ELC U-Cup

Type ELW Rod Wiper

Service Description: Standard elastomeric sealing elements. Economical designs for maximun sealability or wiping action in non-friction-sensitive situations and moderate environments.

Gland Compatibility:

For ELC: C= Cap Seal glands. D= Industrial Reciprocating glands.

S= Industrial Static glands. M= Mil-G-5514 Rev F glands.

G= Mil-G-5514 Rev G glands.

For ELW: W= Rod Wiper/Scraper glands, Mil-G-5514 Rev. F Rods.

X= Rod Wiper/Scraper glands, Mil-G-5514 Rev. G Rods.

Y= Rod Wiper/Scraper glands, Std. Industrial Rods.

How to specify your Seal Science U-Cup or Wiper .

Format Example: ELC-M-103-2-04

Type	Gland Code	Size	Gland Width (0,1, or 2 Backups)	Material Code


ELC	-M	-103	-2	-04


U-Cup	Mil-G-5514F Gland	-103 Gland	2 Backup Size	Nitrile Elastomer Mil-R-7362

Fractional Inch Size Specification

Seal Science elastomeric U-Cups can also be specified for the standard fractional inch glands described in the PolyKing™ section of this catalog.

Format Example: ELC-S-0250-5000-P

Type	Depth	Cross Section	Inside Diameter	Material


ELC	-S	-0250	-5000	-P


U-Cup	S= Std. Depth D= Deep Size Gland = .290-.275 (Refer to PolyKing™ Design Chart)	¼" Cross Section	5 Inch I.D.	90 Durometer Polyurethane (Use letter code for fractional inch parts.)
